MONEL WIRE MESH
Monel wire mesh is a type of woven wire mesh made from Monel alloy, which is primarily composed of nickel (approximately 67%) and copper, with small additions of iron, manganese, carbon, and silicon. Monel wire mesh offers several distinct functions and features, including:
1. Corrosion Resistance: Monel wire mesh is highly resistant to corrosion, particularly in marine and chemical environments. It provides excellent resistance to seawater and other corrosive mediums, making it suitable for offshore and marine applications.
2. High Temperature Resistance: Monel wire mesh maintains its mechanical properties at elevated temperatures, making it suitable for use in high-temperature applications such as aerospace and chemical processing.
3. Strength and Durability: Monel wire mesh exhibits high tensile strength and excellent mechanical properties, providing durability and long-term performance in demanding environments.
4. Non-magnetic Properties: Monel wire mesh is non-magnetic, which makes it suitable for use in applications where magnetic interference needs to be minimized.
5. Versatile Applications: Monel wire mesh is utilized in various applications, including filtration, separation, and containment in industries such as chemical processing, oil and gas, marine, and aerospace.
Overall, Monel wire mesh is valued for its combination of corrosion resistance, high temperature performance, and strength, making it a preferred material in critical and demanding industrial applications.
 |  |
Performance characteristics
High strength: Monel alloy wire mesh has high tensile strength and compressive strength, and can withstand greater external forces and pressures.
Excellent corrosion resistance: Monel alloys perform well in a variety of corrosive media, including seawater, acidic solutions, alkaline solutions, etc. Its corrosion resistance is due to the synergistic effect of nickel and copper in its alloy composition, which can effectively resist the erosion of corrosion factors such as chloride ions.
Good workability: Monel alloy can be formed and processed by a variety of processing methods, such as cold processing, hot processing, welding and so on. This gives Monel alloy wire mesh high flexibility and plasticity in the manufacturing process.
Specifications and parameters
Wire diameter: from 0.05mm to 1.8mm.
Mesh size: can be expressed by the number of mesh, such as 2 mesh, 4 mesh, 10 mesh, 20 mesh, 40 mesh, etc., the higher the mesh number, the smaller the mesh.
Weaving method: Common weaving methods are plain weaving and twill weaving and so on.
Width and length: Customized according to customer needs, the common width range is between 0.1m and 1.5m, and the length can reach tens of meters.
Application field
Chemical industry: Used to manufacture lining and filtering elements for various chemical equipment to prevent the equipment from being corroded by corrosive media.
Oil industry: Used as a sealing element and filter element for components such as pipes, valves and pumps in oil extraction and processing.
Food processing industry: Due to its non-toxic and corrosion-resistant characteristics, it is widely used in the filtration and separation system of food processing equipment.
Marine development: used for the production of seawater desalination equipment, Marine platform protection nets, etc., to resist the corrosion of seawater.
